Mobile pressure blast machine

Technical Data:

Mobile pressure blast machine TZP 100 ARMI is specially designed for ecological soda blasting. It can be used with all light blast media.

  • Media capacity: 100 lt
  • Maximum compr. air pressure: 8 bar
  • Working pressure: 3 –8 bar
  • Compressed air feed line: 1"
  • Blast hose: Ø19x7mm, 10 m long
  • Media consumption: 0,5 – 1,5 kg
  • Air consumption: 0,8 – 6 Nm3/min
  • Height: 1250 mm
  • Width: 510 mm
  • Depth: 510 mm
  • Weight: 150 kg (empty machine)

Standard equipment

  • Blasting hose with connectors, L = 10 m (standard)
  • Vibrator with flow regulator
  • Air filter/moisture separator
  • Pressure regulator
  • Manually adjustable media valve
  • Pneumatic remote controls with ''deadman'' handle
  • Independent remote control of media and air flow


Optional equipment

  • Blasting hose with connectors, L = 20 m
  • Water jet pump with hoses and connectors
  • Soft nozzle for Wet blasting

Applications:

  • the removal of graffiti from brick and concrete
  • the cleaning of boat bottoms
  • the removal of carbon, char, and odors from buildings damaged by fire
  • refurbishing stainless steel kitchen equipment
  • removing oil and grease from engines
  • removing offensive odors in stairwells
  • cleaning washrooms in manufacturing facilities
  • removing paint from brick and steel
  • removing surface rust and paint from cars
  • line removal off highways
  • the soda blasting approach has proved to be successful time and time again.
